PCIe Gen3x4 U.2 SSD — SGM9700E Series

Supports PCIe Gen3x4 32Gb/s

Excellent read/write performance

Support TRIM, S.M.A.R.T, NCQ

Support DEVSLP

Support garbage collection algorithm (GC), bad block management, wear leveling

High stability, support 7x24 hours non-stop operation

Support hig

National Service Hotline:

0755-83048021

Consult now Other products

Product details

Applications

Servers

Rail Transportation

Video Surveillance

Network Security

HPC

Overview

SiliconGo U.2 SSD adopts NVMe protocol and is mainly designed for enterprise server applications with high read/write speed and high IOPS, with outstanding performance.

Specifications

Model Name	SGM9700E
Interface	PCIe Gen3x4 32Gb/s
Flash Type	TLC
Capacity	2TB ~ 8TB
Form Factor	M.2 2280
Sequential R/W (MB/s, Max)	3500 / 1800
Random R/W (IOPS, Max)	435,000 / 372,000
Max. Channels	8
Thermal Sensor (Y/N)	Y
DRAM (Y/N)	Y
Hardware Write Protection	N
Data Encryption	SM2/SM3/SM4
S.M.A.R.T (Y/N)	Y
Size (W x L x H mm)	69.85 x 100.0 x 9.2
Operation Temperature	0 ~ +70°C
Storage Temperature	-40°C ~ +85°C
MTBF	≥2,000,000 h
